Windows Server |
|
|
Windows Server is a Microsoft Windows application allowing user to run transputer/i860/Alpha bootable files directly from Windows environment.
Windows Server can load and serve parallel applications created with Inmos 2nd generation ANSI C and occam2 Toolsets (*.btl), 3L Parallel C/C++/Fortran/Pascal (*.b4), Logical Systems Workbench (*.tld), PACT Parallel C (*.run), Portland C for i860 and WindRiver VxWorks (for DEC Alpha AXP).
Both 16-bit and 32-bit versions available. Windows Server Package 95 (32-bit) has a couple of advanced features and works under Windows 95 and Windows NT using direct port access, virtual device driver (under Windows 95) or kernel-mode driver (under Windows NT). Please contact Elcom Ltd for more information.
|
|
|
Shareware version also available (with limited features).
|
|
|
|
|
|
|
|
|
|
|
|
- easy-to-use menu-driven interface
- smart tool bar with tooltips & status bar
- controls any number of boards from one PC host (installable hardware interface)
- installable and user-configurable software protocols
- tuning polling timeouts (useful for fast computers)
- "protocol" mode with output to screen and/or file: logging all transactions from/to server
- background execution (accurate message dispatching) with different priority levels
- execution control (always can terminate & suspend serving)
|
|
|
Windows Library |
|
|
Windows library is a complete set of libraries, include files, examples and documentation for creating transputer programs with MS Windows interface.
Libraries available for INMOS ANSI C Toolset, INMOS i860 Toolset, 3L Parallel C/C++, Logical Systems C Workbench, Portland C for i860 and VxWorks.
|
|
|
|
|
|
|
|
|
|
|
|
- event-driven architecture like with Microsoft SDK
- fast I/O file operations using Windows API calls with buffering
- about 200 Windows functions: complete API interface
- modal and modeless dialogs
- access to resources (Menus, Dialogs, Bitmaps, Icons and Cursors) through resource script files created with SDK Paint & Dialog editor or Borland Resource WorkShop
- working with bitmaps (load/save, palette management etc.)
- printing capabilities
- clipboard manager functions
- memory management functions like GlobalAlloc, GlobalLock etc. to access HOST virtual memory from transputers
- caching/multithreading GDI functions
- user protocol extensions via DLL libraries
|
|
|
|
|
|
DDE Library |
|
|
DDE protocol is the simplest way to integrate your transputer programs with other Windows applications. Using DDE, you can animate and visualize you calculations in real-time as well as drive (automate) other programs.
|
|
|
- DDE Server
- DDE Client
- DDE Automation
- Documentation and samples
|
|
|
Demo and evaluation software |
|
|
|
|
|
 Windows Server Package 95 Lite (for Windows 95 and NT, 21/02/96, 912578 bytes) - the 'lite' version of Windows Server Package 95. Has a couple of limitations in comparison with the full version.
|
|
|
Windows Server Package 95 Lite (for Windows 3.1 with Win32s, 21/02/96, 854194 bytes) - the same package as above, but designed to run under Windows 3.1 (doesn't use Windows Registry).
|
|
|
|
|
|
Patches and Updates |
|
|
Important! All patches affecting the same file are cumulative. So, if you have more than one patch for some program, you need to apply them in the same sequence as they appear here.
|
|
|
|
|
|
Windows Server Package 4.0 patch 1 (13/02/96, 77953 bytes) - a patch for Windows Server 4.0 correcting SetTextColor function. Unzip this file, put it into your WSP directory (where wserver.exe is located) and run.
|
|
|
Windows Server Package 4.0 patch 2 (19/02/96, 28344 bytes) - a patch for Windows Server 4.0 correcting ExecFileDialog function. The same operation as above.
|
|
|
Windows Server Package 95 (Lite) patch 1 (25/03/96, 28402 bytes) - a patch for Windows Server 95 (Lite) correcting WM_COMMAND message processing. Unzip this file, put it into the directory where wlib.dll is located, and run.
|
|
|
|
|
|
Documentation |
|
|
|
|
|
 Windows Server Package 95 Release Notes (04/03/96, 6756 bytes)
|
|
|
Windows Server Package 95 Programmer's Guide (Vol.1) (13/02/96, 33601 bytes)
|
|
|
Windows Server Package 95 Programmer's Guide (Vol.2) (13/02/96, 65219 bytes)
|
|
|
Windows Server Package 95 Programmer's Reference (Vol.1) (04/03/96, 102964 bytes)
|
|
|
Windows Server Package 95 Programmer's Reference (Vol.2) (13/02/96, 41408 bytes)
|
|
|
Windows Server Package 95 Programmer's Guide & Reference (help files) (06/12/96, 293885 bytes)
|
|
|
Windows Server Package 95 User's Guide (help file) (29/01/96, 59424 bytes)
|
|
